Datalogic PowerScan PM9600 DPX, 2D, DPM, disp., multi-IF, kit (USB), RB

Datalogic PowerScan PM9600 DPX – Cordless 2D Scanner for Demanding Workplaces

The PowerScan PM9600 DPX is built for situations where your scanner has to keep working from the first scan of the shift to the last. The 433 MHz cordless connection gives you full freedom of movement — no cable to trip over or pull loose when things get busy.

Reads Codes Even on Difficult Surfaces

Beyond standard 1D and 2D barcodes, the PM9600 DPX handles DPM codes (Direct Part Marking) — codes that are laser-etched, engraved, or dot-peened directly onto metal, plastic, or other materials. If you have parts or components that cannot be labelled with a sticker, this scanner identifies them reliably without any workarounds.

Built-in Display for On-the-Spot Feedback

The integrated display shows scanner status, collection data, and error messages right on the device. You do not need to glance at a separate screen after every scan. The four-key quantity keypad and vibration feedback support fast pick-and-pack work, keeping your hands in the flow rather than reaching for a keyboard.

Works with the Systems You Already Have

The multi-interface connection means the PM9600 DPX runs over both USB and RS232. Switching between them is a settings change — you do not need a different model for different systems. The charging and transmitter cradle handles both battery charging and acts as the radio base station for the wireless link.

Battery That Lasts the Whole Shift — and Beyond

The removable 3,350 mAh battery is designed for hot-swap replacement: when it runs low, you swap in a fresh pack and carry on. The scanner never needs to leave the floor for a recharge. A 36-month warranty covers the device.

What's in the Box

• ·Cordless 2D/DPM scanner PowerScan PM9600 DPX
• ·Charging and transmitter cradle
• ·USB cable
• ·Power supply unit with EU power cable
• ·Removable 3,350 mAh battery

Key Specifications

• ·Scan engine: 2D imager with DPM support
• ·Wireless: 433 MHz
• ·Interfaces: USB, RS232 (multi-interface)
• ·Display: yes
• ·Vibration feedback: yes
• ·Battery: 3,350 mAh, removable
• ·Warranty: 36 months
• ·Country of origin: Vietnam

Get in touch with Vaivatta if you want to confirm compatibility with your current point-of-sale or inventory management system — we help with setup.
