Star TSP743DII-24, RS232, 8 dots/mm (203 dpi), cutter, dark grey

Star TSP743DII-24 Receipt Printer for Your Counter

When Friday evening is in full swing and customers are queuing at the till, your receipt printer needs to keep up — not hold things up. The Star TSP743DII-24 is built for exactly that: daily hard use in restaurants, cafés, and retail shops.

Print speed that keeps the queue moving

At 250 mm/s, the receipt is in the customer's hand before they've finished putting their card away. As a direct thermal printer, there are no ink cartridges or ribbons to replace — one less thing to think about on a busy shift.

The built-in automatic cutter trims each receipt cleanly after every print. No tearing, no jams at the cut point.

Flexible paper handling

The printer accepts three paper widths — 58 mm, 80 mm, and 82.5 mm — with a maximum print width of 80 mm. That means you can use whatever roll you already have on the shelf rather than hunting for a specific size.

Resolution is 203 dpi (8 dots/mm), so prices, product names, and totals come out sharp and legible — even at full speed.

RS232 connection for your POS

The TSP743DII-24 connects to your till via RS232 serial interface. It's a well-established, reliable connection that works with most POS systems and software without extra configuration. The printer supports both ESC/POS and Star command sets, giving you broad compatibility across POS platforms.

Please note: The power supply unit is ordered separately — check what accessories you need to complete your counter setup.

Technical details

• ·Print technology: direct thermal — no ink or ribbons
• ·Resolution: 203 dpi (8 dots/mm)
• ·Paper width: 58 / 80 / 82.5 mm
• ·Maximum print width: 80 mm
• ·Print speed: 250 mm/s
• ·Interface: RS232
• ·Auto-cutter: included
• ·Command sets: ESC/POS and Star
• ·Warranty: 24 months
• ·Colour: dark grey
• ·Country of origin: China

Vaivatta can help with setup

Not sure whether the TSP743DII-24 works with your current POS, or how to wire up the RS232 connection? Get in touch with Vaivatta. We help with installation questions so you don't have to figure out the technical details on your own.
