Elo 1302L, 33.8cm (13,3''), Projected Capacitive, 10 TP, Full HD, USB, kit (USB), black

Elo 1302L – a touchscreen built for daily use

The Elo 1302L is a 13.3-inch touchscreen designed to hold up under continuous use at a café counter, restaurant till, or retail checkout. Projected Capacitive technology reads ten touch points at once, so the screen responds to your fingers just as smoothly as your phone.

Sharp image — even in a bright room

Full HD resolution (1920 × 1080) and 270 cd/m² brightness keep the picture clear in a sunlit shop or behind a busy counter. The antiglare surface cuts distracting reflections, and the 170-degree viewing angle — both horizontally and vertically — means your customer and your staff member can both read the screen standing side by side.

One cable does the job

The monitor connects to your till system via USB — touch input and power travel down the same cable, so there is nothing extra to route. In the box: USB and HDMI cables, a power supply unit, and a power cable. Everything you need to get running is there when you open the packaging.

Video connections cover HDMI and VGA, so the display works with the majority of till computers and tablet stands already in use.

Fits the counter or the wall

The VESA 75 × 75 mm mount lets you attach the screen to a wall bracket or a separate stand, whichever suits your setup. At 13.3 inches the footprint on the counter is compact, but there is enough screen area for a point-of-sale application or an order-entry system without feeling cramped.

Technical specifications

• ·Screen size: 33.8 cm (13.3")
• ·Resolution: 1920 × 1080 pixels, 16:9 aspect ratio
• ·Touch technology: Projected Capacitive, 10 touch points
• ·Brightness: 270 cd/m², contrast ratio 800:1
• ·Response time: 25 ms
• ·Viewing angle: 170°/170° (H/V)
• ·Connections: HDMI, VGA, USB Type-C, Micro-USB, audio output
• ·Mount: VESA 75 × 75 mm
• ·Warranty: 36 months
• ·Country of origin: China
• ·Colour: black

Vaivatta can help with setup

If you need a hand getting the monitor running or connecting it to an existing till system, get in touch with Vaivatta and we will work through the right solution with you.
