Elo I-Series 5 Steel, with PoE, 25,7cm (10,1''), Projected Capacitive, 10 TP, USB, USB-C, BT, Ethernet, Wi-Fi, QCS6490,

Elo I-Series 5 Steel – a till terminal that holds up on the counter

The Elo I-Series 5 Steel is a steel-bodied all-in-one touch terminal built for daily use in cafés, restaurants, and retail shops. The 10.1" screen sits comfortably on a counter, checkout desk, or wall — the VESA mount (75×75 mm) keeps your installation options open from day one.

A display that keeps up when the queue is out the door

The Projected Capacitive touchscreen reads ten contact points at once, so tapping through an order works even with damp hands or thin gloves. The 1920×1200 resolution, 387 cd/m² brightness, 160/160° (H/V) viewing angle, and 900:1 contrast ratio keep the image clear whether the room is flooded with afternoon sun or lit by a single pendant lamp. With a 30 ms response time the screen reacts the moment you touch it — no half-second lag when a customer is waiting.

One cable, no clutter

The terminal draws power directly from the network cable via Power over Ethernet (PoE), so you do not need a separate power socket at the counter. One cable handles both data and power, which means a tidier desk and a simpler installation. When you do need to connect peripherals, the ports are ready: USB-A, USB-C, Bluetooth, Ethernet, and Wi-Fi 802.11ax cover the card readers, receipt printers, and barcode scanners you are likely already using.

Enough headroom for a full Saturday service

The Qualcomm Snapdragon QCS6490 processor, 8 GB of RAM, and 64 GB of storage keep your till software running smoothly when the tables are full and orders are coming in fast. Android 14 with Google Mobile Services (GMS) means your point-of-sale apps install and update exactly as you would expect — no special configuration, no workarounds.

Built for the spills and scrubs of a working kitchen or shop floor

The steel chassis carries an IP54 rating, so the occasional splash on the counter is not a problem. The screen itself is rated IP65, which adds confidence when you are wiping down with cleaning spray at the end of the night. The steel frame handles the knocks that would finish a cheaper device.

36-month warranty and hands-on setup support

The I-Series 5 Steel comes with a 36-month warranty. Vaivatta will help you get it connected to your existing till system — get in touch and we will work through the setup together so you can focus on your customers from day one.
